2-Channel Digital Signal Generation
The DM91-102G offers dual-channel digital signal generation which is ideal for automotive diagnostics and testing.
It provides precise control over signal output for reliable performance in complex electrical systems.
Integrated CAN Data Function Equipped with CAN data functionality
Supports modern vehicle communication protocols and enables accurate simulation of CAN bus signals for advanced troubleshooting and repair tasks.

Signal characteristics can be adjusted in real time: the waveform, amplitude, frequency and number of missing teeth can be adjusted at will in the signal output department, which greatly facilitates the fault determination.

Channel: Dual Channel
Supports USB Storage Device: Connecting with PC or transferring test data to PC
CAN bus test rates are 10K, 20K, 33.3K, 50K, 62.5K, 83.3K, 125K, 250K, 500K and 1M.
5hr battery life
3.2-inch HD display: 320*240 resolution
Special Wave Rate Selection: Manual or Automatic Scanning
Waveform: square wave, sine wave, square wave X+Y, sine wave X+Y, DC voltage
Frequency: 1HZ-5KHZ
Range: 0-20V
Duty ratio: 1-100%
X: 1-199
Y: 1-9
